| Name | Value |
|---|---|
| Product Status | Obsolete |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 250 V |
| Current - Continuous Drain (Id) @ 25°C | 360mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 0V |
| Rds On (Max) @ Id, Vgs | 4Ohm @ 200mA, 0V |
| Vgs(th) (Max) @ Id | - |
| Gate Charge (Qg) (Max) @ Vgs | - |
| Vgs (Max) | ±15V |
| Input Capacitance (Ciss) (Max) @ Vds | 350 pF @ 25 V |
| FET Feature | Depletion Mode |
| Power Dissipation (Max) | 1.6W (Ta) |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | SOT-89-3 |
| Package / Case | TO-243AA |
